ABB E234CT-ERD Timer Relay On Delay 681 5

Abb TEST
Abb TEST
ABB EA 681 5 4013614350658

Abb timer relay, with the following features:

  • Rated control supply voltage (Us): 24...240 V AC - 24...48 V DC
  • Impulse withstand voltage (Uimp): Input circuit 4 kV
  • Rated insulation voltage (Ui): Input circuit/output circuit 300V
  • Rated operating current AC-12 (Ie):(230 V) 6 A
  • Rated operating current AC-15 (Ie):(230 V) 3 A
  • Rated operating current DC-12 (Ie):(24 V) 6 A
  • Rated operating current DC-13 (Ie):(24 V) 2 A

Request info about this product

ABB E234CT-ERD Timer Relay On Delay 681 5

€85.59 Tax included
€85.59

ABB E234CT-ERD Timer Relay On Delay 681 5

€85.59
Tax included

-20€

EXTRA

Add the coupon code in the payment page

Limited-time promotion
Items Available: 3
Altre disponibilità dal produttore
qty

ABB E234CT-ERD Timer Relay On Delay 681 5

€85.59

Buy it within and receive it from Thursday, 1 January
klarna Pay in installments with Klarna
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

They are used when the control of utilities is required according to a time interval.

Features:

  • Abb series
  • Time interval: 0.05 s ... 100 h
  • Rated frequency: DC 50 / 60 Hz
  • Output:1 c/o (SPDT) contact
  • Terminal Type:Screw Terminals
  • Degree of protection:Housing IP50 - Terminals IP20
  • Overvoltage Category:III
  • Pollution degree:3
  • Tightening torque: 0.5 ... 0.8 Nm
  • Cable stripping length: 7 mm
  • Recommended screwdriver: Pozidriv 1 - 0.8 x 4
  • Mounting position: any
  • Ambient temperature: In operation -20 ... +60 °C - In storage -40 ... +85 °C
  • Maximum permissible operating altitude: 2000 m
  • RoHS Declaration: According to EC Directive 2011/65/EC
  • UL/CSA maximum operating voltage: Output circuit 300 V AC
  • UL/CSA contact rating:C300
  • Tightening torque UL/CSA:4.43 ... 7.08 in lb

UL/CSA Cable Sections

  • Flexible 1x 18-14 AWG
  • Flexible 2x 18-16 AWG
  • Rigid 1x 20-12 AWG
  • Rigid 2x 20-16 AWG

Reference Standards:

  • CAN/CSA C22.2 No.14
  • IEC/EN 63000
  • IEC/EN 61812-1
  • UL 508

DIN rail mounting

  • TH35-15 (35 x 15 mm mounting rail) according to IEC 60715
  • TH35-7.5 (35 x 7.5 mm Mounting Rail) according to IEC 60715

Connection capacity:

  • Flexible 1x 0.5 ... 2.5 mm² Flexible
  • Flexible 2x 0.5 ... 1.5 mm² Rigid
  • Rigid 1x 0.5 ... 4 mm² Rigid
  • Rigid 2x 0.5 ... 1.5 mm² Rigid

Short circuit protection devices:

  • Output Circuit NC - Fuses Type F 6A
  • Output Circuit NO - Fuses Type F 10A

Timer Relay Type

  • ON-Delay
  • OFF-Delay
  • Pulse ON
  • Pulse OFF
  • Flasher Starting with ON
  • Flasher Starting with OFF
  • Pulse Former

Dimensions (mm)

  • Width: 17.5 mm
  • Height: 70 mm
  • Depth: 63 mm
  • Net Weight: 0.053 kg
