Lovato Platinum 4-ways lever manipulator without lock LPSJ400

Lovato
LOV LPSJ400 8013975297643

Lovato Platinum Joystick Lever Manipulator:

  • 4 ways without mechanical lock
  • Metal diameter 22 mm
  • Auxiliary contacts 4NA
  • Complete with contact
  • Instable
  • Fixing screw with washer.

Request info about this product

Lovato Platinum 4-ways lever manipulator without lock LPSJ400

€49.10 Tax included
€49.10

Lovato Platinum 4-ways lever manipulator without lock LPSJ400

€49.10
Tax included

-20€

EXTRA

Add the coupon code in the payment page

Limited-time promotion
qty

Lovato Platinum 4-ways lever manipulator without lock LPSJ400

€49.10

Buy it within and receive it from Thursday, 18 December
klarna Pay in installments with Klarna
Two-year warranty
Easy return within 14 days

Features:

  • Material Zamak for metal parts, polyamide and polycarbonate for plastic parts. NBR rubber bellows
  • Degree of protection (IEC) IP66, IP67 and IP69K
  • IEC/EN 690V rated insulation voltage
  • Conventional free air thermal current Ith IEC 10A
  • Designation according to UL/CSA and IEC/EN 60947-5-1 A300 Q300
  • Operating current AC15 12/24/48/120V 6A - 240V 3A
  • Operating current DC13 12/24/48/125 0.55A 250V 0.27V
  • Contact resistance m? ?20
  • Mechanical life cycles 1000000
  • Terminal tightening torque max Nm 1
  • Screw connections Fixing screw with washer
  • Fixing base With contacts included
  • Degree of protection (UL) Type 1, 2, 3R, 4, 4X, 12, 12K
  • Operating temperature min °C -25 - max °C +60
  • Storage temperature min °C -40 - max °C +70
  • Classification ETIM 8.0 EC000632 - Control switch, joystick.

Data sheet

Type:
Joystick
