Bticino Thermal-magnetic Circuit Breaker 16A 2 Poles 16KA Curve D 2 Modules FT82D16
BTI FT82D16
8005543701805
Bticino thermal-magnetic circuit breaker:
- Power In 16A
- 2 Poles
- Breaking capacity Icu 16KA
- Tripping curve D
- 2 Modules
Bticino Thermal-magnetic Circuit Breaker 16A 2 Poles 16KA Curve D 2 Modules FT82D16
€65.67
Tax included
€65.67
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 4
Pay in installments with Klarna
Curve D, trip threshold of 10 to 20 times In, for application of circuits with high inrush currents (motors, transformers, etc.).
A circuit breaker is a safety device that can automatically (i.e., without external intervention) interrupt the flow of electric current in an electrical circuit in the event of an overcurrent.
Characteristics:
- Reference Standard IEC EN 60947-2
- Voltage 400 Vac
- Degree of protection IP20
- Height 83mm
- Width 35.6mm
- Depth 76mm
- Maximum cable cross section 25/35mmq
There are no reviews
Data sheet
- Voltage: 400VAC
- Modules: 2
- Poles: 2P
- Curve: D
- Power: 16KA
- Degree of protection: IP20
- Amps: 16A
- Circuit Protections: Circuit breakers
