Connected switch Vimar Eikon View Wireless 20592.0
VIW 20592.0
8007352628366
Mechanism Diverter connected Vimar Eikon VIEW Wireless for:
- for incandescent lamps 500 W
- LED lamps 100 W
- electronic transformers 250 VA
- fluorescent lamps 120 W.
- Configuration by App View Wireless for Bluetooth technology system and Amazon App for Zigbee technology
- Compatible with Alexa, Google Home and IFTTT, through the appropriate Zigbee gateway or hub.
To be completed with interchangeable keys codes 20021 - 20021.B - 20021.N.
Connected switch Vimar Eikon View Wireless 20592.0
€37.54
Tax included
€37.54
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 27
: 3
Pay in installments with Klarna
Frequently bought together
The connected electronic diverter mechanism allows you to control a load via the on-board push button, via a wireless connection and from a traditional remote push button. The device has the possibility to be controlled with two different radio standards (exclusive between them); Bluetooth mesh (default) or Zigbee (settable through View Wirelles app). The Bluetooth mesh network implies the presence of the 20597-19597-14597 gateway while a Zigbee gateway (e.g. Amazon Echo Plus, Echo Show or Echo Studio) is required for dialogue via Zigbee.
The device is equipped with:
- 2 interlocked relay outputs for realizing diverter function
- Front button for controlling the connected load.
Automatically opens the relays for thermal protection.
The electronic diverter can be connected to existing wired inverted/diverter outputs to make the load function "connected".
The electronic deviator must be powered with the same L and N that power the load. In case of installation with wired diverters/invertersters, the electronic diverter must be connected in such a way as to be always powered and therefore installed in place of the most distant wired diverter of the load.
Characteristics:
- Rated supply voltage: 100-240 V~, 50/60 Hz
- Power dissipation: 0,55 W
- Transmitted RF power: < 100mW (20dBm)
- Frequency Range: 2400-2483.5 MHz
- Terminals: - 2 terminals (L and N) for line and neutral - 1 terminal (P) for connection to the wired remote control (e.g. art. 20008-19008-16080-14008). The maximum distance between the IoT device and the push-button is 50 m with a minimum section cable of 1.5 mm2 - 2 terminals (1 and 2) for the diverter output
- Front button used both for load control and as configuration button
- RGB LED that indicates the status of the load (settable from the View Wireless App) and the status of the configuration (flashing blue)
- In Bluetooth technology mode, up to 2 radio devices (art. 03925) can be associated with the device, allowing the control of the actuator or the activation of a scenario
- Operating temperature: -10 ÷ +40 °C (for indoor use)
- Degree of protection: IP20.
ottimo prodotto. gia lo conoscevo.indispensabile
Il prodotto è buono ma il costo considerevole
Data sheet
- Smart System: Connected Multiway Switches
