Abb Disconnect Switch SD202/40 2P 40A 2 Modules M990415
ABB M990415
4016779904155
Abb SD202/40 disconnect switch with the following characteristics:
- Rated voltage: Minimum 440V 12V
- Rated operating voltage: Maximum 440V AC - Minimum 125V DC
- Operating voltage: Maximum 462V AC - Maximum 131V DC - Minimum 12V AC
- Impulse withstand voltage: 4 kV at 2000 m 5 kV - at sea level 6.2 kV
- Rated current: 40 amps
- Rated conditional short-circuit current: 25kA
- Rated service short-circuit rating: 25kA
- Number of poles: 2
- Number of modules: 2
- Degree of protection: IP20 housing - with cover IP40
Abb Disconnect Switch SD202/40 2P 40A 2 Modules M990415
€30.93
Tax included
€30.93
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 80
: 12
They are designed fordisconnection of power lines according to IEC EN 60947-3, allowing for safe maintenance of downstream connected devices, and for control under load. They are also equipped with a plumbable control lever in both positions.
For proper operation, upstream protection with devices against short circuit and overload (fuses, circuit breakers) is required.
The disconnect switch, otherwise called the voltage disconnect switch, has the same as a circuit breaker, but on a larger scale: it is, in fact, responsible for shutting off the flow of power to the electrical distribution stations. This is mainly to ensure the safety of the power plant and primarily of the people working inside it since one of its special features is to separate the flow of energy from the working environments. Another special feature of this instrument is its ability to be able to detect defects in the electrical flow and isolate them. When the defect is then corrected, the disconnector will make the current flow normally again.
Features:
- Input voltage type: AC/DC
- Rated frequency (f): 50/60 Hz
- Power loss: at Rated Operating Conditions per pole 2.27 W
- Electrical resistance: 10000 AC cycle(s)
- Mechanical resistance: 20000 cycle(s)
- Number of c/o contacts: 0
- Number of NC contacts: 0
- Number of NO contacts: 2
- Overvoltage category: III
- Tightening torque: 2.8 Nm
- Actuator type: Lever
- Screw terminal type: Two-way failsafe cylinder lifting terminal
- Switch type: Off
- Actuator Marking: I/O
- Actuator material: Insulation group II, red, sealable
- Enclosure material: Insulation class I, RAL 7035
- Mounting location: Any
- Recommended screwdriver: Pozidriv 2
- Cover color: Gray
- Connection capacity: 10 / 10 mm² busbar - Flexible 0.75 ... 16 mm² - Rigid 0.75 ... 25 mm² - Flexible 0.75 ... 25 mm²
- Terminal type: Screw terminals
- Ambient temperature: In operation -25 ... +55 °C - In storage -40 ... +70 °C
- Pollution degree: 3
- Ambient conditions: 28 cycles at 55 °C / 90-96 % and 25 °C / 95-100 %
- Product width: 35 mm
- Product height: 88 mm
- Product depth: 69 mm
- Built-in depth (t2): 69 mm
There are no reviews
Data sheet
- Voltage:
- 440V
- Modules:
- 2
- Poles:
- 2P
- Degree of protection:
- IP20
- Amps:
- 40A
- Circuit Protections:
- Disconnectors
- Operating voltage:
- AC
