Bticino MATIXGO Standard Schuko flat socket P40 2-module grey JG4140A16F
BTI JG4140A16F
8005543716632
Bticino MATIXGO Standard German Schuko Flat Socket:
- Voltage 250Vac
- Current In 16A
- 2 modules
- Colour grey
- Poles 2P+T
- 19 mm and 26 mm spacing in two-pole configuration
- Protected cavities
- Side ground contacts for German standard plugs
- Suitable for standard Italy 2 P and 2 P+T 10/16 A plugs, German standard 2 P+T 16 A plugs.
To be mounted on frames J4702-J4703-J4704-J4707.
Unlike the traditional schuko socket, the flat is characterized by the surface of the socket, when the plug is inserted, it slides inside the well; it returns to its initial position when the plug is pulled out.
Bticino MATIXGO Standard Schuko flat socket P40 2-module grey JG4140A16F
€12.87
Tax included
€12.87
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 491
: 160
Pay in installments with Klarna
Frequently bought together
The schuko electrical outlet also known as the German outlet allows any plug (small, large and schuko) to be inserted inside.
Features:
- Clamp type: screw
- Clamp capacity: 2 x 4 mm2
- Stripping length: 11 mm
- Compatible with flexible and rigid cables
- Penetration by solids/liquids: IP21D
- Impact proof: IK04
Materials:
- Case and cover : PC (polycarbonate)
- Halogen Free
- UV Resistant
- Self-extinguishing: 850°C/30s for insulating parts that hold live parts in place, 650°C/30s for other parts of insulating materials
- Storage temperature: -10° C to +70° C
- Use temperature: -5° C to +35° C.
There are no reviews
Data sheet
- Main Commands: Current Sockets
