Siemens Residual Current Circuit Breaker 1P+N 32A 2 Modules 5SU13537KK32
SIE 5SU13537KK32
4001869306483
Siemens differential circuit breaker with the following characteristics:
- Number of poles: 1P+N
- Rated current: 32 amps
- Rated residual current: 30mA
- Rated short-circuit capacity: 4.5kA
- Type of A differential
- Number of modules: 2
Siemens Residual Current Circuit Breaker 1P+N 32A 2 Modules 5SU13537KK32
€59.51
Tax included
€59.51
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 119
: 10
Pay in installments with Klarna
Features:
- Number of poles 2
- Number of poles with protection 1
- Design of poles 1 pole+N
- Class of the trip characteristic C
- Mechanical service life (switching cycles) typ. 10 000
- Overvoltage category III
- Pollution degree 2
- Voltage type of utilization voltage AC
- Insulation voltage (Ui) rated value 264 V
- Rated value impulse withstand voltage 4 000 V
- Impulse withstand current for (8/20) µs 1 kA
- Frequency of use 50 Hz
- Frequency of supply voltage rated value 50 Hz
- Degree of protection IP20, for installation in distribution board, with conductors connected
- Height 90 mm
- Width 36 mm
- Depth 77 mm
- Recessed depth 70 mm
- Number of width modular units 2
- Influence of ambient temperature max. 95% relative humidity
- Ambient temperature during operation: min. -25 °C - max. 55 °C
- Ambient temperature during storage: min. -40 °C - max. 75 °C
There are no reviews
Data sheet
- Modules: 2
- Poles: 1P+N
- Curve: C
- Power: 4.5KA
- RCD Type: A
- Differential current : 0.03A
- Amps: 32A
- Circuit Protections: RCBO
