Schneider Compact INS125 4P 125A Disconnect Switch Black 28911

Schneider
Schneider
SNR 28911 3303430289111

Schneider Compact INS125 disconnect switch with the following characteristics:

  • Product type or component: Disconnect switch
  • Number of poles: 4P
  • Mains type: DC AC
  • Mains frequency: 50/60 Hz
  • Rated insulation voltage: 750V AC 50/60 Hz
  • Rated impulse withstand voltage: 8 kV
  • Conventional thermal current in open air: 125A at 60°C

Request info about this product

Schneider Compact INS125 4P 125A Disconnect Switch Black 28911

€129.53 Tax included
€129.53

Schneider Compact INS125 4P 125A Disconnect Switch Black 28911

€129.53
Tax included

-20€

EXTRA

Add the coupon code in the payment page

Limited-time promotion
Items Available: 10
logo priority: 1
Altre disponibilità dal produttore
qty

Schneider Compact INS125 4P 125A Disconnect Switch Black 28911

€129.53

Calculate shipping cost
Buy it within and receive it from Wednesday, 12 November
klarna Pay in installments with Klarna
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Compact INS125 is a 4-pole non-automatic switch-disconnector with a black rotary handle. It is suitable for isolation with visualized disconnection as defined by IEC 60947-1 and IEC60947-3. The operating current is 125A at 415VAC in AC22A and AC23A categories. The rated voltage is 500VAC 50/60Hz or 250VDC.

The black rotary handle is designed to provide excellent maneuverability and high performance in the event of current interruption. Compact INS125 is a Class II front-insulated device in accordance with IEC 60664.

Rated operating current:

  • AC-22A: 40 A "AC" "50/60 Hz" 220/240 V
  • AC-22A: 40 A "AC" "50/60 Hz" 380/415 V
  • AC-22A: 40 A "AC" "50/60 Hz" 440/480 V
  • AC-22A: 40 A "AC" "50/60 Hz" 500 V
  • AC-23A: 32 A "AC" "50/60 Hz" 500 V
  • AC-23A: 40 A "AC" "50/60 Hz" 220/240 V
  • AC-23A: 40 A "AC" "50/60 Hz" 380/415 V
  • AC-23A: 40 A "AC" "50/60 Hz" 440/480 V
  • DC-22A: 40 A DC 125 V 2 poles in series
  • DC-23A: 40 A DC 125 V 2 poles in series
  • DC-22A: 40 A DC 250 V 4 poles in series
  • DC-23A: 40 A DC 250 V 4 poles in series


Maximum power:

  • AC-23: 11 kW at 220/240 V "AC" "50/60 Hz"
  • AC-23: 18.5 kW at 500/525 V "AC" "50/60 Hz"
  • AC-23: 20 kW at 380/415 V "AC" "50/60 Hz"
  • AC-23: 22 kW at 440 V "AC" "50/60 Hz"

Features:

  • Rated short-circuit closing capacity: 154 kA with upstream circuit breaker 690 V "AC" at "50/60 Hz" - 20 kA single switch-disconnector 690 V "AC" at "50/60 Hz"
  • Rated operating voltage: 250 V DC - 690 V "AC" "50/60 Hz"
  • Pollution degree: 3
  • Control type: Rotary operation
  • Operation lever color: Black
  • Mounting mode Fixed
  • Mounting bracket: DIN rail - Plate
  • Cable cross-section: 1,550 mm²
  • Mechanical durability: 15000 cycles
  • IP degree of protection: IP40
  • Degree of protection IK: IK07
  • Operating ambient temperature: -25/+70 °C
  • Storage temperature: -50/+85 °C

There are no reviews

Data sheet

Poles:
4P
Amps:
125A
Circuit Protections:
Disconnectors
