Schneider Compact INS63 4P 63A Disconnect Switch Black 28903
SNR 28903
3303430289036
Schneider Compact INS63 disconnect switch with the following characteristics:
- Product type or component: Disconnect switch
- Number of poles: 4P
- Mains type: DC AC
- Mains frequency: 50/60 Hz
- Rated insulation voltage: 690V AC 50/60 Hz
- Rated impulse withstand voltage: 8 kV
- Conventional thermal current in open air: 63A at 60°C
Schneider Compact INS63 4P 63A Disconnect Switch Black 28903
€75.61
Tax included
€75.61
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 9
: 2
Pay in installments with Klarna
Compact INS63 is a 4-pole non-automatic switch-disconnector with a black rotary handle. It is suitable for isolation with visualized disconnection as defined by IEC 60947-1 and IEC60947-3. The operating current is 63A at 415VAC in AC22A and AC23A categories. The rated voltage is 500VAC 50/60Hz or 250VDC.
The black rotary handle is designed to provide excellent maneuverability and high performance in the event of current interruption. Compact INS63 is a Class II front-insulated device in accordance with IEC 60664.
Rated operating current:
- AC-22A: 40 A "AC" "50/60 Hz" 220/240 V
- AC-22A: 40 A "AC" "50/60 Hz" 380/415 V
- AC-22A: 40 A "AC" "50/60 Hz" 440/480 V
- AC-22A: 40 A "AC" "50/60 Hz" 500 V
- AC-23A: 32 A "AC" "50/60 Hz" 500 V
- AC-23A: 40 A "AC" "50/60 Hz" 220/240 V
- AC-23A: 40 A "AC" "50/60 Hz" 380/415 V
- AC-23A: 40 A "AC" "50/60 Hz" 440/480 V
- DC-22A: 40 A DC 125 V 2 poles in series
- DC-23A: 40 A DC 125 V 2 poles in series
- DC-22A: 40 A DC 250 V 4 poles in series
- DC-23A: 40 A DC 250 V 4 poles in series
Maximum power:
- AC-23: 11 kW at 220/240 V "AC" "50/60 Hz"
- AC-23: 18.5 kW at 500/525 V "AC" "50/60 Hz"
- AC-23: 20 kW at 380/415 V "AC" "50/60 Hz"
- AC-23: 22 kW at 440 V "AC" "50/60 Hz"
Features:
- Rated short-circuit closing capacity: 15 kA single switch-disconnector 500V AC at 50/60 Hz - 75 kA with upstream circuit breaker 500V AC at 50/60 Hz
- Rated operating voltage: 500V AC 50/60 Hz - 250V DC
- Pollution degree: 3
- Control type: Rotary maneuvering
- Operation lever color: Black
- Mounting mode Fixed
- Mounting bracket: DIN rail - Plate
- Cable cross-section: 1,550 mm²
- Mechanical durability: 20000 cycles
- IP degree of protection: IP40
- Degree of protection IK: IK07
- Operating ambient temperature: -25/+70 °C
- Storage temperature: -50/+85 °C
There are no reviews
Data sheet
- Poles: 4P
- Amps: 63A
- Circuit Protections: Disconnectors
