ABB residual current circuit breaker 1P+N 25A 30mA AC type 6kA 2 modules DS1C25AC30
ABB DS1C25AC30
Abb differential thermomagnetic circuit breaker, 2 modules, DIN mounting (universal for any switchboard on the market), poles 1P+N, 25 amperes, breaking capacity 6kA, voltage 230 Vac, differential current Idn 30mA, type AC, trip curve C.
ABB residual current circuit breaker 1P+N 25A 30mA AC type 6kA 2 modules DS1C25AC30
€102.51
Tax included
€102.51
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 11
The magnetothermal differential is, therefore, a system that combines the functions of the circuit breaker with the magnetic and thermal characteristics.
The magnetothermal differential switch in the electrical system integrates three different protections
- the magnetic one for short circuits that can put an entire building at risk of fire;
- the thermal one for overloads in the supply of electrical energy (e.g. more than one household appliance in operation);
- the differential which protects the subject from a current leakage.
The AC residual current circuit breaker tripping is assured for sinusoidal alternating currents applied suddenly or slowly increasing (CEI EN 61008-1).
Features:
- Abb series
- Voltage 230 Vac
- Current In 25A
- Interrupting capacity Icn 6kA
- Intervention curve C
- Differential current Idn 30mA
- AC differential type
- 2 modules
- 1P+N poles
- Frequency 50/60 Hz
- Degree of protection IP20
Data sheet
- Modules:
- 2
- Poles:
- 1P+N
- Curve:
- C
- Power:
- 6KA
- RCD Type:
- AC
- Differential current :
- 0.03A
- Amps:
- 25A
- Circuit Protections:
- RCBO
