Sick IME08 inductive proximity sensor with cable 1040840
SIK 1040840
Sick IME M12 inductive proximity sensor, with the following features:
- Supply voltage: 10V DC ... 30V DC
- Residual ripple ≤ 10 %
- Voltage drop ≤ 2V
- Availability delay ≤ 100 ms
- Hysteresis 5 % ... 15 %
- Reproducibility ≤ 2 %
- Thermal drift (d Sr) ± 10 %
- EMC according to EN 60947-5-2
- Continuous current IA ≤ 200 Ma
- No-load current: ≤ 10 mA
- Degree of protection: IP67
- Short-circuit protection: YES
- Reverse polarity protection: YES
- Trigger pulse protection: YES
Sick IME08 inductive proximity sensor with cable 1040840
€23.35
Tax included
€23.35
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 1
Other technical characteristics:
- Vibration and shock resistance: 30 g, 11 ms/10 Hz...55 Hz, 1 mm
- Ambient operating temperature: -25 °C/+75 °C
- Material, active surface: plastic, PA 66
- Length 52 mm
- Useful thread length 34 mm
- Maximum tightening torque: ≤ 5 Nm
- Thread size: M8 x 1
- Diameter: Ø 8 mm
- Switching distance Sn: 1.5 mm
- Protected switching distance Sa: 1.215 mm
- Metal mounting: flush
- Switching frequency 4,000 Hz
- Connection type: Cable, 3-wire, 2 meters
- Switching output: PNP
- Output function: N/O
- Electrical equipment: DC 3-wire
- Degree of protection: IP67
