ARE4E4X bipolar cable 0.6/1 kV 2x1x16 sq. mm ARE4E4X/2X16B
9X9 ARE4E4X/2X16B
ARE4E4X two-core cable with the following characteristics:
- Formation (No. x sq. mm) 2 x 1 x 16
- Conductor diameter: 4.9 mm
- Minimum insulation + sheathing thickness: 1.25 mm
- Minimum insulation thickness + sheathing ( phase ): 1.5 mm
- Outer diameter: 16.3 mm
- Max. electrical resistance at 20°C: 1.91 ohm/ km
- Current carrying capacity in free air 40°C: 70A
- Current carrying capacity in tube in air 40°C: 56A
The selling price is per meter.
The producers of our cables are:
- Baldassari cavi
- Icel
- La Triveneta
- Prysmian
This product doesn t benefit from the right of withdrawal Cable cut and therefore non-refundable
ARE4E4X bipolar cable 0.6/1 kV 2x1x16 sq. mm ARE4E4X/2X16B
€1.94
Tax included
€1.94
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 407
: 181
Pay in installments with Klarna
Two-year warranty
Bipolar visible helix carrier-beam cable for aerial laying with aluminum conductors, XLPE insulated, under XLPE sheath.
Characteristics:
- Conductor: aluminum cord, rigid noncompact, class 2
- Insulation: XLPE cross-linked polyethylene compound
- Sheath: XLPE cross-linked polyethylene compound
- Sheath color: gray
- Rated voltage Uo/U: 0.6/1 kV
- Maximum operating temperature: 75°C
- Minimum laying temperature: 0°C
- Minimum operating temperature: -15°C (in the absence of mechanical stress)
- Maximum short-circuit temperature: 160°C
- Maximum tensile stress: 250 kg for two-core cable, 500 kg for four-core cable
- Minimum bending radius: 18 times the maximum outer diameter
Conditions of use: Suitable for low-voltage power transmission by overhead lines; laid on supports, in pipe or conduit, along building facades.
