Vortice Centrifugal Vacuum cleaner SUPER 100 11952
VOR 0000011952
8010300119526
Air and odour extractor Vortice model SUPER centrifugal, wall application, white colour, Rated diameter 100 mm.
Vortice Centrifugal Vacuum cleaner SUPER 100 11952
€225.70
Tax included
€225.70
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 6
Pay in installments with Klarna
Characteristics:
- White ABS plastic resin construction
- 3-speed fan through optional TRIO-S device (code 12871), consisting of: induction type motor with starter capacitor, equipped with protective thermo-fuse and self-lubricating bushings, forward paddlewheel centrifugal impeller
- Rated diameter 100 mm
- Saturated filter signalling device.
Technical specifications:
- Max. current consumption at max. speed (A) 0.5
- Max. current consumption at min. speed (A) 0,36
- Rated Duct Diameter (mm) 100
- Frequency (Hz) 50
- IP X4 Degree of Protection
- Insulation Class II
- Ø Exhaust (mm) 97
- Weight (Kg) 3.77
- Max. power consumption at max speed (W) 105
- Max. power consumption at min speed (W) 50
- Max. ambient temp. continuous operation (°C) 50
- Voltage (V) 220-240
- Free field sound emission [dB(A)] 3m 41.9
- Max. flow rate at max. speed (l/s) 77
- Max. flow rate at max. speed (m³/h) 280
- Max. flow rate at min. speed (l/s) 38
- Max flow rate at min speed (m³/h) 140
- Max pressure at max speed (mmH2O) 50
- Max pressure at max speed (Pa) 490
- Max. pressure at min. speed (mmH2O) 23
- Max. pressure at min. speed (Pa) 226
- Sound pressure Lp [dB (A)] 3m - max vel 48.6
- Sound pressure level Lp [dB (A)] 3m - min vel 41.9
- RPM max 2200
- RPM min 1400
Data sheet
- Diameter: 100
- Type: Centrifugal
