Lovato Modular Contactor 63A AC1 4NO 24VAC/DC 3 Modules CN6310024
LOV CN6310024
8013975143841
Lovato modular contactor, with the following characteristics:
- Operating current AC1 and AC-7a ≤400V: UN 63
- Operating current AC3 and AC-7b ≤400V: UN 30
- IEC/EN rated insulation voltage Ui: 440V
- Rated impulse withstand voltage Uimp: kV 4
- Minimum switching capacity: ≥17V ≥50mA
- Power dissipation per pole (average value) Ith: 8W
- Rated auxiliary voltage Us: 24V AC/DC
- Number of poles: 4
- Number of DIN modules: 3
- IEC Conventional free air thermal current Ith: UN 63
Lovato Modular Contactor 63A AC1 4NO 24VAC/DC 3 Modules CN6310024
€83.69
Tax included
€83.69
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 3
Pay in installments with Klarna
Other technical features:
- Auxiliary contacts: NO nr.4
- Average coil consumption ≤20°C: rushing 5W, gripping 5W
- Working voltage: pick up min %Noi 85, max %Noi 110, throw out min %Noi 20, max %Noi 75
- Mechanical life:3000000 cycles
- AC3 electric life:150000 cycles
- AC1 electrical life: 100000 cycles
- Operating temperature: min °C -25 max °C+70
- Storage temperature: min °C -30 - max °C80
- Maximum altitude: 2000m
- Instrument Terminals PZ2
- Weight 425 grams
- Front IP grade: IP20
- Pollution degree: 3
- Fixing: 35mm DIN rail
Average Time:
Closing NO:
- min SM 15
- max SM 20
Opening No:
- min SM 35
- max SM 45
Tightening torque for coil end:
- max Nm 0.6
- max Ibin 0.6
Tightening torque for terminals:
- max Nm 2
- max Ibin 1.48
Conductor section:
- Coil terminal: min mm² 1, max mm² 2.5
- Power supply terminal: min mm² 1.5, max mm² 16
