Notifier 8-Zone Conventional Fire Panel VSN8-LT
NOT VSN8-LT
9000005366768
Notifier 8-zone conventional fire control panel with the following features:
- Voltage: 27 VDC ± 7%
- 2 250mA siren outputs
- A maximum of 25 conventional detectors/buttons can be connected to each zone
- Designed for installation of small and medium-sized fire detection systems
- Dimensions: 315mm(H) x 380mm(W) x 100mm(D)
- Weight: about 3kg (without batteries)
- Operating temperature -5°C/+45°C (recommended +5°C/+35°C)
- Humidity: 5 ÷ 95% (without condensation)
- Degree of protection: IP30
- Certified in accordance with EN 54-2 and EN 54-4
- Material: Painted steel enclosure
Notifier 8-Zone Conventional Fire Panel VSN8-LT
€345.27
Tax included
€345.27
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 9
Notifier's new Conventional 8 Zone control panel, is designed and engineered for the installation d Italy small and medium-sized fire detection systems in those places where it is necessary to interface with a user-friendly, high-performance control panel. The control panel is accessible and configurable by entering a password. The VSN control panel has 4 levels of detection, which allows it to recognize whether an alarm is coming from a sensor, a button, or whether it has been generated by an open or short circuit. Each Zone can be configured as a normal fire detection zone or as a delayed or comparison contact (the system resets the first alarm coming from the zone if a second alarm does not occur within 10 minutes). The VSN control panel allows different delay times to be set for siren activation depending on the source of the alarm (buttons or sensors). LEDs on the control panel provide complete control of the system, and the keypad allows for quick and easy operation. The control unit provides a default configuration that can be adapted to any type of system quickly and easily.
There are no reviews
Data sheet
- Type:
- Control units
- Zone:
- 8
