Urmet video recorder AHD 4K 16-channel H.265 1097/626 hybrid HVR
UTD 1097/626
8021156071418
Urmet Building&Retail HVR Hybrid Video Recorder (Hybrid Video Recorder) enables complete management of cameras with AHD, CVI, TVI, AHD and IP technology:
- 16 channels
- K Series
- HD included: 1000 GB hard disk (default)
- Compression formats: Video: H.265 / H.264 Audio: ADPCM 8kHz 16bit
- Video inputs: 16-CH input with BNC video / 8-CH input with IP video (up to 24-CH with IP video input) up to 24-CH with mixed Analog + IP input
- Audio Inputs/Outputs: 16-CH RCA Input / 1-CH RCA Output
- Recording resolution: 8M (3840x2160) / 5M (2560x1944) / 4M (2560x1440) / 3M (2048x1520) / 1080P (1920x1080) / 720P (1280x720) / WD1 (960x576)
Easy to configure and with performance to meet all kinds of plant solutions, the new HVRs enable revamping of old plants while enabling major cost savings.
Urmet video recorder AHD 4K 16-channel H.265 1097/626 hybrid HVR
€558.75
Tax included
€558.75
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 2
Pay in installments with Klarna
Features:
- Recording frame rate: Main-stream Analog: 8MP :10fps (per single ch) 5MP:15fps (per single ch), 4MP: 20fps (per single ch) 1080P:25fps (per single ch) - NTSC: 30fps (per single ch) IP - Sub-stream Analog PAL?704*576: 10fps (per single ch) - Sub-stream Analog NTSC 704*480: 10fps (per single ch)
- IP recording bandwidth: 64Mbps ~192Mbps (default 64Mbps; for each analog channel excluded, bandwidth increases by about 8Mbps, up to a maximum of 192Mbps)
- Maximum output bandwidth: 192Mbps
- Hard disk interface: Max. 1 Sata HDD (Max 8T)
- HD included: 1000GB hard disk drive (default)
- Storage spaces: External USB device/Network
- Web software/Internet Explorer 10/11 / Edge /Chrome/Opera /Firefox / UVS pro
- Intelligent Video Analysis (for coaxial inputs ): PID - LCD - PD&VD - FD - FR - SOUND DETECTION / VIDEO TAMPERING
- Intelligent Video Analysis ( * depending on IP camera model ): *Perimeter Intrusion Detection (PID), *Line Crossing Detection (LCD), *Stationary Object Detection (SOD), *Pedestrian and Vehicle Detection(PD & VD), Heat Map (HM) *Face Detection (FC), *Crossing Counting (CC), *Sound Detection, *Video Tampering , LPD (License plate detection) , RSD (Rare sound detection)Alarm I/O: 8-CH alarm input, 1-CH alarm output
- PDA Mobile Software: Urmet iUVS PRO (iOS, Android)
- USB ports: No. 1 - 2.0 + No. 1 - 3.0
- Ethernet: 1 RJ45 100/1000 Base-T
- Network Protocols: TCP/IP, DHCP, UDP, Urmet DDNS / UrmetDDNS2 with ID, P2P, PPPOE, Cloud Storage , SMTP , HTTPS , PPPPoE , FTP , RTSP , UPNP , SNMP
- BNC Output: 1 Out (704*576) Only for SPOT functionality for analog channels
- VGA Output: YES
- HDMI Output: YES
- Power Consumption: 20W
- Power Supply: 12V / 5A
- Operating temperature: 0°C~+40°C / below 90%RH
- Cooling fans: YES
- Dimensions (WXHXP): 380X340X50 mm
- Weight 3kg
There are no reviews
Data sheet
- Type: Video recorders
- System: Hybrid
- Resolution: 8MP (4K)
- Channels: 16
