Urmet Lite series Video recorder HVR 16 channels AHD 5M-N H265 1097/576
UTD 1097/576
8021156071388
Urmet Lite series Video recorder HVR 16-channel AHD 5M-N H265 is characterized by the most advanced features, compatibility with cameras in Analog technology, CVI, TVI and AHD 720P, 1080P, 5M IP, IP Wi-Fi.
Urmet Lite series Video recorder HVR 16 channels AHD 5M-N H265 1097/576
€336.65
Tax included
€336.65
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 13
: 2
Pay in installments with Klarna
The HVRs can be remotely managed by both Windows and MAC systems, compatible with the UVS software and the iUVS pro App that allows a convenient management from all smartphones, iPads and tablets both Android and iOS. Among the main features also the UTC function that allows viewing and management of the OSD menu of the cameras directly from HVR.
Features:
- Compression formats: Video: H.265 / H.264 - Audio: G.711a
- Video inputs: 16-CH input with BNC video / 4-CH input with IP video (up to 20-CH with IP video input) (up to 20-CH with mixed video input: Analog + IP)
- Audio Inputs/Outputs: 4-CH RCA Input / 1-CH RCA Output
- Recording Resolution: 5M Lite(1280x1944)/ 4M Lite(1280x1440) / 1080P(1920x1080) / 720P(1280x720) / WD1(960x576)
- Recording Frame Rate: Main Stream Analog: 5MP-Lite:12fps(per single ch) / 4MP-Lite:16fps(per single ch) / 1080P:15fps(per single ch) / 720P:PAL:25fps(per single ch) / NTSC:30fps(per single ch) IP:PAL:25fps(per single ch) / NTSC:30fps(per single ch) Sub-stream Analog Max PAL:704*576:10fps(per single ch) NTSC:704*480:10fps(per single ch)
- IP Recording Bandwidth: 16Mbps ~80Mbps (default 16Mbps, for each analog channel excluded, the bandwidth increases about 4Mbps)
- Maximum output bandwidth: 96Mbps
- Hard Disk Interface: Max. 1 Sata HDD (Max. 8T)
- HD included: 1000 GB hard disk (default)
- Storage Spaces: External USB device /e-SATA / Network
- Web software / Multilingual client: Internet Explorer 10/11 / UVS pro
- Intelligent Video Analysis (for coaxial inputs): NO
- Intelligent Video Analysis ( * depending on IP camera model ):*Perimeter Intrusion Detection (PID), *Line Crossing Detection (LCD), *Stationary Object Detection (SOD), *Pedestrian Detection (PD), *Face Detection (FC), *Cross Detection (CC), Sound Detection, Video Tampering
- Alarm I/O: 4-CH Alarm Input, 1-CH Alarm Output
- PDA Mobile Software: Urmet iUVS PRO (iOS, Android)
- USB Ports : N°1 - 2.0 + N°1 - 3.0
- Ethernet : Self-adaptive interface RJ-45 100M/1000MB
- Network Protocols : TCP/IP, DHCP, UDP, Urmet DDNS / UrmetDDNS2 with ID, P2P, PPPOE, Cloud Storage , SMTP , HTTPS , PPPPoE , FTP , RTSP , UPNP , SNMP
- BNC Output: NO
- VGA Output: YES
- HDMI Output: YES
- Power Consumption: 18.3W (13.8W without HD)
- Power Supply: 12V / 2A
- Operating Temperature: 0°C~+40°C / below 90%RH
- Cooling Fans: YES
- Dimensions (WXHXP): 300X53X227 mm
- Weight: 3kg
There are no reviews
Data sheet
- Type: Video recorders
- System: AHD
- Resolution: 5MP
- Channels: 16
