Chaffoteaux Aquanext Plus Link 250 Sys Heat Pump Water Heater 3069783
CFF 3069783
5414849966376
Chaffoteaux Aquanext Plus Link model 250 Sys heat pump water heater, underfloor aerothermal in class A+ for the production of domestic hot water through a renewable source.
Predisposition to 'coupling with boiler and / or solar thermal and dedicated function for integration with photovoltaic systems.
- Nominal storage capacity 245 liters
- Refrigerant type R-134a
- Energy efficiency class A+
- XL load profile
The AQUANEXT PLUS LINK heat pump water heater can be coupled with condensing boilers from the ADVANCE range, ZELIOS solar systems through the new COMBI and SYSTEM functions, and photovoltaic panels.
Chaffoteaux Aquanext Plus Link 250 Sys Heat Pump Water Heater 3069783
€2,730.74
Tax included
€2,730.74
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Out of stock
Incoming
Pay in installments with Klarna
Frequently bought together
MAXIMUM COMFORT ASSURED:
- Lowest heat pump heating time on the market: 3:59 h (200l model) ensuring maximum hot water availability
- Aquanext Plus Link heats water up to 62°C on heat pump and to 75°C with integration
- New Silent function makes Aquanext Plus even quieter, among the best in its class
- New display, even more intuitive than its predecessors, quantifies the number of showers available in real time
SUPERIOR SAVINGS:
- Aquanext Plus Link has one of the highest COP ratings on the market. It ensures maximum utilization of the free, renewable energy in the air
- Heat pump working range with outdoor air temperature from -10 to 42°C, so you are assured of savings even in extreme weather conditions
- Possibility of solar thermal integration in the 250-liter version guarantees unparalleled savings
VERY SIMPLE INSTALLATION AND MAINTENANCE:
- Filter that ensures cleanliness of the air entering the evaporator allowing efficient and long-lasting operation
- Easy transport thanks to integrated straps
- Replaceable and inspectable heater without draining the product
- In case of ducted configurations, removal of air duct grilles is possible to reduce pressure drops
ABSOLUTE SAFETY:
- Magnesium lanode and Pro-Tech provide double protection against corrosion
- Condenser wrapped outside the tank is not in direct contact with domestic water, ensuring maximum hygiene
Features:
- Insulation thickness mm =50
- Lower coil exchange surface area 0.65 cubic meters
- Water connection diameter G 3/4 M
- Maximum operating pressure MPa 0.6
- Heat losses (Pes) (Values obtained with outdoor air temperature 7°C and relative humidity 87%, inlet water temperature 10°C and set temperature 55°C) 23W
- Minimum local storage temperature 1 Degree
- Heating element power 1500W
- Electrical protection IPX4
- Maximum voltage/power consumption V/W 220-240/2500
- Standard air flow rate (automatic modulation) m3/h 650
- Minimum volume of the installation room (Value that guarantees proper operation and easy maintenance in the case of non-ducted product. However, proper operation of the product is guaranteed up to the minimum height of 2.090 m) 30 cubic meters
- Empty mass 115 kg
- COP 3.14
- Heating time 5:24 h:min
- Min/max air temperature -10/42 degrees
- Max temperature only heat pump/with R °C 62/75
- Sound power 55 dB(A)
- Average electrical power consumption 700W
- Seasonal efficiency (average climate) 129%
- V40 333 liters
- Refrigerant charge 1300 g
- GWP 1430
- CO2 equivalent 1.86 t
Connections:
- ¾ pipe cold water inlet
- Pipe ¾ hot water outlet
- Pipe ¾ auxiliary circuit inlet (SYS and TWIN)
- Pipe ¾ auxiliary circuit outlet (SYS and TWIN)
- Pipe ¾ auxiliary circuit inlet (TWIN SYS)
- Pipe ¾ auxiliary circuit outlet (TWIN SYS)
- Pipe ¾ for recirculation circuit (SYS and TWIN SYS)
There are no reviews
Data sheet
- Type: Water heaters
- Model: Heat Pump
- Installation: Vertical
- Capacity: 245 Liters
- Energy class: A+
- Series: Aquanext Plus Link
