Siemens S7-1200 SM1222 Output Module 16 DO RELAIS 2A 6ES72221HH320XB0

Brand: Siemens

Cod: SIE 6ES72221HH320XB0 EAN: 6940408101968

Siemens S7-1200 SM 1222 digital output module , DQ 16x relay/2A, with the following features:

Supply voltage: Allowable range, lower limit (DC) 20.4V - Allowable range, upper limit (DC) 28.8V
Input current from backplane bus DC 5 V, max. 135 mA
Digital outputs from load voltage L+, max. 11 mA / relay coil
Power dissipation: typ. 8.5W
Digital outputs: 16
Short-circuit protection No (to be provided externally)
Output voltage: Rated value (DC) DC 5V ... DC 30V - Rated value (AC) 5 ... 250V AC
Output current: for signal "1" rated value 2A
Cable length: with shielding, max. 500 m - without shielding, max. 150 m
Diagnostic alarm: yes

€231.57 Tax included

€231.57

€231.57
Tax included

EXTRA

Add the coupon code in the payment page

Limited-time promotion

Items Available: 35

Pay in installments with Klarna

Two-year warranty

Easy return within 14 days

Are you a professional ?

Request access to

Other technical features:

Diagnostic display LEDs for output status: yes
Allowable potential difference between different circuits AC 750 V for 1 minute
IP20 degree of protection
Free fall: Drop height, max. 0.3 m; five times, in shipping packaging
Ambient temperature for storage/transportation: -20/+40°C
Atmospheric pressure according to IEC 60068-2-13: Storage/transport, min. 660 hPa - Storage/transport, max. 1 080 hPa
Relative humidity: Operating at 25 °C without condensation, max. 95 %.
Front connector required
Housing material: plastic
Dimensions: Width 45mm - Height 100mm - Depth 75mm
Weight: 260 grams approx.
