ABB 3P Contactor 205A 100-250V AC/DC 1NA+1NC AF205301113
ABB AF205301113
7320500480564
Abb contactor, with the following characteristics:
- Rated main circuit operation voltage 1000 Vac
- DC operation control circuit rated voltage 100-250 Vac
- 3 poles
- DIN connection (universal for any switchboard on the market)
- Main circuit rated frequency 50/60 Hz
- Operating current 205 amperes
ABB 3P Contactor 205A 100-250V AC/DC 1NA+1NC AF205301113
€767.35
Tax included
€767.35
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 2
Pay in installments with Klarna
A contactor is a device for closing and opening electrical circuits, mostly high voltage circuits, by remote control.
IEC 17-3 defines a contactor (contactor) as a device capable of interrupting or establishing current within a circuit. To do this, the device opens and closes contact channels between the system and the power structure. In short, a switch of sorts to be used for all eventualities.
Features:
- Abb series
- Rated main circuit operation voltage 1000 Vac
- Rated control circuit operating voltage DC 100-250 Vac
- Operating current 205 amps
- Rated main circuit frequency 50/60 Hz
- 3 poles
- Number of NO main contacts 3
- Number of NC main contacts 0
- Number of NO auxiliary contacts 1
- Number of NC auxiliary contacts 1
- Terminal type: main circuit bars
- Main terminal degree of protection IP20
- Width 105 mm
- Depth 152 mm
- Height 196 mm
- Net weight 2.4 kg
There are no reviews
Data sheet
- Type: Contactors
- Voltage: 1000VAC
- Poles: 3P
- Amps: 205A
