Dimmer for Strip Led Lef 24-48 Vdc button control and 0-10V signal MINICUBO24P
LEF MINICUBO24P
8054521539367
Constant voltage Lef Led Strip dimmer with the following characteristics:
- 24Vdc or 48Vdc input voltage
- Output voltage 24Vdc or 48Vdc
- Output current: 11A
- Output power: 264W
- Command: PUSH | 0-10V | POT47k
- Degree of protection: IP20
- Device not for independent use
Use only SELV approved power supplies for electrical safety and power performance appropriate to the load.
Dimmer for Strip Led Lef 24-48 Vdc button control and 0-10V signal MINICUBO24P
€24.02
Tax included
€24.02
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 5
Features:
- Brightness controller for LED modules 24Vdc or 48Vdc
- Brightness adjustment via: push button (PUSH no voltage), 0-10V signal, 47Kohm potentiometer
- PWM output voltage frequency: 250Hz
- Synchronization of multiple interfaces by wiring (max10)
- "LEVEL MEMORY" function
- "STATUS MEMORY" function (at 100%, light on after black-out)
- Short circuit protection (SCP)
- Ambient operating temperature Ta -10°C ÷ +40°C
- Maximum temperature at the point Tc 80°C
Construction Characteristics:
- Plastic container
- Device not for independent use
- Electrical class of protection III
- Small size container
- Degree of protection IP20
Other information:
- Install in a suitable place and in the absence of voltage, comply with the nameplate data
- Use only SELV power supplies approved for electrical safety and power performance appropriate to the load
- Connections are low voltage, observe clearances and isolations to line voltage lines
- Pulsed line: keep connections isolated from the grid and limited in length
- Dimmer memory is maintained only with continuous power supply
There are no reviews
Data sheet
- Type:
- Dimmer
- Voltage:
- 24/48V
- Degree of protection:
- IP20
