Schneider Compact Circuit Breaker NSX160B 4X160A 25KA LV430395
SNR LV430395
3606480006623
Schneider Compact NSX160B switch, with the following characteristics:
-
Rated operational voltage [Ue] 690 V AC 50/60 Hz
-
Rated insulation voltage [Ui] 800 V AC 50/60 Hz
-
Rated impulse withstand voltage [Uimp] 8 kV
-
Rated current [In] 160A
-
AC" grid type
-
Mains frequency "50/60 Hz
-
Breaking capacity 25 kA
- 4 poles
Schneider Compact Circuit Breaker NSX160B 4X160A 25KA LV430395
€331.17
Tax included
€331.17
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Out of stock
Incoming
Features:
- Schneider Series
- 4 poles
- Neutral position left
- Nominal current [In] 160A at 40 °C
- Rated operational voltage [Ue] 690 V AC 50/60 Hz
- Rated insulation voltage [Ui] 800 V AC 50/60 Hz
- Rated impulse withstand voltage [Uimp] 8 kV
- AC" grid type
- Mains frequency "50/60 Hz
- Utilization category category A
- Breaking capacity 25 kA
- Type of control lever
- Fixed mounting mode
- Mechanical endurance 40000 cycles according to IEC 60947-2
- Back plate mounting bracket
- Upper connections front side
- Bottom connections front side
- Connection pitch 35 mm
- Width 140 mm
- Height 161 mm
- Depth 86 mm
- Pollution degree 3
- Degree of protection IP40
- Degree of protection IK07
- Operating ambient temperature-25...70 °C
- Storage temperature -50...85 °C
There are no reviews
Data sheet
- Type:
- Switches
- Poles:
- 4P
- Power:
- 25KA
- Amps:
- 160A
