Self-powered head amplifier 4IN/4OUT 35 db ABLA 271173

Fracarro
FRA 271173 8016978051052

Fracarro AMP435SA self-powered head amplifier with 4 satellite inputs, A.B.L.A. technology and output level adjustment, with the following features:

  • Supply voltage: 220-240 Vac
  • Frequency: 50/60 Hz
  • Power consumption 550 @12VmA
  • Maximum LNB absorption: 900 mA
  • Maximum SAT line current: 2000 mA
  • Inputs: 4 SAT
  • Outputs: 4 SAT
  • Dimensions: 160x110x30 mm
  • Power supply dimensions: 145x120x70 mm
  • Working temperature: -10+55 °C
  • SAT-SAT isolation: dB ≥35
  • External power supply PSU1430F (14V, 3A) included in the package
Request info about this product

Self-powered head amplifier 4IN/4OUT 35 db ABLA 271173

€143.01 Tax included
€143.01

Self-powered head amplifier 4IN/4OUT 35 db ABLA 271173

€143.01
Tax included

-20€

EXTRA

Add the coupon code in the payment page

Limited-time promotion
Items Available: 18
logo priority: 1
Altre disponibilità dal produttore
qty

Self-powered head amplifier 4IN/4OUT 35 db ABLA 271173

€143.01

Buy it within and receive it from Thursday, 25 September
Two-year warranty
Secure Payment
Easy return within 14 days
Purchase with tax breaks

SAT:

  • SAT bandwidth MHz: 950-2150
  • SAT gain: dB self-adjusted A.B.L.A. 16-36
  • Slope: dB 6
  • CAG dynamics: dBµV Depends on output level set: 65-85 @101dBµV; 85-105 @121dBµV
  • Maximum SAT output level: dBµV 101-121
  • SAT return loss: 10 dB


Strengths:

  • Output level adjustment with ABLA technology for each Satellite input.
  • With Automatic Building Level Adjustment (A.B.L.A.) technology, the amplifier maintains the set output level even when the input signal strength varies
  • A.B.L.A. LEDs light up when the automatic output signal adjustment is operating properly; if the input level is too low, the LED turns off and the product behaves as a normal fixed-gain Satellite amplifier (36dB)
  • High Satellite output level (121dBµV) and excellent separation between inputs (35dB)
  • Powered remotely via Satellite lines 1 (VL), 2 (HL) and 3 (VH) or by DC connector on the side of the mechanism
  • DC throughput on the Satellite HH line
  • Voltage pass-through from DC port down protected from overloads and controlled by dip switch located on the side of the mechanics
  • Dual power ports to be able to offer more robustness to the system
  • Current overload protection on the DC port
  • Ideal for medium to large installations or where there are long distances between multiswitches
  • Easy to install due to new trimmers and standard input coloring
  • External power supply PSU1430F (14V, 3A) included in the package

There are no reviews

Data sheet

Type:
Amplifiers
Version:
4IN/4OUT
