Chint Disconnectable Fuse Holder Base WSB18-32 32A 1P+N 1 Module 80505
CHT 80505
8058776757613
Chint sectional fuse holder base WSB18-32 with the following characteristics:
- Number of Poles: 1P+N
- Rated current: 32 A
- Rated voltage: 230/400 Vac
- Insulation voltage: 690 Vac
- Fuse size: Ø 10.3X38 mm
- Degree of protection: IP20
- Number of modules: 1
Chint Disconnectable Fuse Holder Base WSB18-32 32A 1P+N 1 Module 80505
€4.99
Tax included
€4.99
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 9
: 26
Fuse holder bases for housing WS18/32 series cylindrical fuses for protection against overcurrents due to overloads or short circuits. For fuses with dimensions: 10.3x38 mm.
Features:
- Reference standard: IEC/EN 60269-2
- Number of Poles: 1P+N
- Rated current: 32 A
- Rated voltage: 230/400 Vac
- Isolation voltage: 690 Vac
- Fuse size: cylindrical
- Fuse size: Ø 10.3X38 mm
- Power Dissipation: 3 W
- Number of DIN modules (1 DIN = 18 mm): 1
- Degree of Protection: IP20
- Dimensions: 62.5x80x18 mm (HxWxD)
There are no reviews
Data sheet
- Type:
- Fuse holder
- Size:
- 10.3X38
- Voltage:
- 230/400VAC
- Modules:
- 1
- Poles:
- 1P+N
- Degree of protection:
- IP20
- Amps:
- 32A
