Call relay Finder 12V AC 1 module DC 131200120000
FIN 131200120000
8012823336640
Finder call relay, with the following features:
- Power supply type: AC (50/60 Hz)/DC
- Voltage 12V AC
- Contact configuration 1 exchange + 1 NO
- 1 DC module
- Max. command pulse duration: 10 s (minimum 100 ms)
- Max. length of push-button connection cables: 100 m
- Rated power AC/DC V A (50 Hz)/W 3/2.5
- Operating range AC/DC (50 Hz) (0.8...1.1)UN
Call relay Finder 12V AC 1 module DC 131200120000
€45.23
Tax included
€45.23
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 57
: 2
When the Set command (S) closes, the relay changes the position of the contacts from open to closed. Only with an impulse of the Reset command (R) will the output contacts open.
Bistable operation with reset command particularly suitable for applications in the service sector: public bathrooms, hospitals, hotels.
Features:
- Finder Series
- Modular bistable
- Fastening on 35 mm bar (EN 60715)
- Standard contacts material AgCdO
- Ambient temperature -10...+60°C
- Degree of protection IP20
Lamp capacity
- incandescent/halogen 230V 800W
- fluorescent with electronic ballast 300W
- fluorescent with rephased electromagnetic ballast 250W
- CFL 150W
- LED 230V 150W
- halogen or BT LED with electronic transformer 150W
- halogen or BT LED with electromagnetic transformer 300W
- Minimum switching load mW (V/mA) 300 (5/5)
There are no reviews
Data sheet
- Type:
- Relays
- Version:
- Call
- Installation:
- Din
