Elettrotek Kabel marine armored cable 3x2.5 GAALSHIP HF 1000 A black 12071G73030M25
EKB 12071G73030M25
Elettrotek Kabel 3x2.5 GAALSHIP HF 1000A marine armored cable with the following characteristics:
- No. of cores x cross section nx mm2: 3 x 2.5
- Sheath color: black
- Outer diameter approx.mm: min 9.6 Nom 10 Maximum 11
- Maximum conductor resistance at 20°C (Ohm/km): 7.4
- Current rating in open air at 45°C (UN): 21
- Short circuit rating 1 second kA: 0.36
- Cable color: black
The selling price is intended per meter.
This product doesn t benefit from the right of withdrawal Cable cut and therefore non-refundable
Elettrotek Kabel marine armored cable 3x2.5 GAALSHIP HF 1000 A black 12071G73030M25
€3.94
Tax included
€3.94
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 900
Pay in installments with Klarna
Two-year warranty
Power and control cable for fixed electrical installations on board ships, not subject to mechanical hazard complying with IEC 60092-352.
Construction:
- Conductor: plain or tinned annealed copper conductor cl. 2 flexible up to 10 mm2 cl. 5 from 16 mm2
- Insulation: GAALTHERM® 595
- Armor: Plain or tinned annealed copper wire braid acc. to IEC 60092-350
Approvals/Certificates:
- RINA / RINAMIL (Italian Naval Registry)
- BV (Veritas Office)
- LR (Lloyd's Register)
- DNV-GL (Det Norske Veritas - Germanisher Lloyd) ongoing
- ABS (American Bureau of Shipping)
- RMRS (Russian Maritime Registry of Shipping)
Technical data:
- Rated voltage: Uo/U 0.6/1 kV
- Test voltage: 3.5 kV
- Temperature range: -40°C to +90°C
- Installation temperature: -5°C
Features:
- Sheath and insulation materials according to: IEC 60092-360
- Design guidelines acc. to IEC 60092-350/353
- Selection and installation of electrical cables acc. to IEC 60092-352
- Cold bending test at low temperatures
- Impact of cold bending at low temperatures
There are no reviews
Data sheet
- Colour: Black
- Section: 2.5 mmq
- Number of cables: 3
