Schneider ZCMD limit switch body 2NO + 2NC cable 5 meters ZCMD41L5
TSI ZCMD41L5
3389110299465
Schneider ZCMD 2 NC + 2 NO limit switch body with 5 meters cable with the following features:
- Number of poles: 4
- Contact composition and type: 2 NC + 2 NO
- Contact operation: Snap-action
- Cable length: 5 m
- Contact insulation: Zb
- Rated insulation voltage: 300V (pollution degree 3) - 400V (pollution degree 3)
- Resistance between terminals: 25 mOhm
- Rated impulse withstand voltage: 4 kV
Schneider ZCMD limit switch body 2NO + 2NC cable 5 meters ZCMD41L5
€76.11
Tax included
€76.11
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 6
Schneider Electric's OsiSense body/contacts assembly with connector has standard contacts and a Zamak body.
It has 2 NO + 2 NC snap-in contacts and is pre-wired (5 m cable).
Features:
- Contact material: Silver plated contacts
- Min. actuation speed: 0.01 m/min
- Short-circuit protection: 6 A fuse cartridge, type gG
- Storage temperature: -4070°C
- Dimensions: height 50 mm width 30 mm depth 16 mm
- Weight: 65 grams
Electrical life:
- 5000000 cycles, DC-13 120 V, 3 W, operating range <60 cycles/m, load factor: 0.5 in accordance with IEC 60947-5-1 appendix C
- 5000000 cycles, DC-13 24 V, 4 W, operating range <60 cycles/m, load factor: 0.5 complies with IEC 60947-5-1 appendix C
- 5000000 cycles, DC-13 48 V, 3 W, operating range <60 cycles/m, load factor: 0.5 complies with IEC 60947-5-1 appendix C
There are no reviews
Data sheet
- Type:
- Limit switch
