Schneider ComPacT MicroLogic NSX250 250A 4P C2542D250 Disconnect Switch
SNR C2542D250
3606482000087
Schneider ComPacT MicroLogic NSX250 250A 4P release with the following features:
- Product range: ComPacT NSX100 250 new generation
- Type of product or component: Trip unit
- Trip release name: Micrologic 2.2
- Trip release technology: Electronic
- Range Compatibility: ComPacT new generation NSX250
- Number of poles: 4
- Release protection functions: LSoI
- Rated trip current: 250 A at 40 °C
- Rated operating voltage: 690V AC 50/60 Hz
- Switch mounting: fixed
- Degree of protection IP40 in accordance with IEC 60529
- Operating ambient temperature: -25/+70 degrees
- Storage temperature: -50/+85 degrees
Schneider ComPacT MicroLogic NSX250 250A 4P C2542D250 Disconnect Switch
€736.16
Tax included
€736.16
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 4
: 1
Frequently bought together
This MicroLogic 2.2 is a 4-pole 4-pole electronic circuit breaker used on ComPacT NSX 160/250 circuit breakers.
Advantages:
- This 160 A electronic circuit breaker is the optimal choice for all standard and specific applications
- Incorporates adjustable long-time overload protection
- Also provides adjustable short-time protection and fixed instantaneous short-circuit protection
- MicroLogic 2.2 signals overloads with alarm LEDs. The green Ready LED flashes if the switch is ready to trip
- This product is part of our EcoStruxure Power architecture when combined with the PowerTag NSX and ComPacT NSX base frame
- Schneider Electric unmistakable green style for the entire ComPacT range
- Estimated 40% reduction in wiring time for panel builders
- Experience easier installation with new ergonomic front plate design
- Get assurance that all auxiliaries are in the right place and check that you have the right coil rating
- New ergonomic lever for easy manual switch operation
Features:
- Ir long pick-up adjustment type (thermal protection): 9 adjustable settings
- Long protection pick-up adjustment range: 100...250A
- Long tr protection delay adjustment type: Fixed
- Long protection delay adjustment range: 11 s at 7.2 x Ir - 16 s at 6 x Ir - 400 s at 1.5 x Ir
- Neutral protection settings: 0.5 x Ir (3D + N/2) - 1 x Ir (4D)
- Thermal memory: 20 minutes before and after tripping
- Short-circuit protection trip setting type Isd: 9 adjustable settings
- Short-circuit protection tripping threshold adjustment range: 1.5...10 x Ir
- Short-time protection delay adjustment type tsd: Fixed
- Instantaneous protection socket adjustment type Ii: Fixed
- Adjustment range of instantaneous protection trip threshold: 3000 A
- Protection class against electric shock: Class II
- Pollution degree: 3 in accordance with IEC 60947-1
There are no reviews
Data sheet
- Type:
- Under-voltage Releases
- Poles:
- 4P
- Amps:
- 250A
