Siemens alarm auxiliary contact Type HQ-EL boxed 3VA99880AB13
SIE 3VA99880AB13
4042949000082
Block of auxiliary signalling contacts Siemens, intervention of exchange contacts type HQ-EL (7MM) electronic, with the following characteristics
- Rated insulation voltage Ui 690 V
- Rated impulse withstand voltage 4 kV
- Rated operational voltage Ue with AC 50 Hz 24 V
- Rated operational voltage Ue with DC 24 V
- Thermal current 0.3A
- Suitable for boxed enclosures series 3VA1 and 3VA20 up to 3VA25
Siemens alarm auxiliary contact Type HQ-EL boxed 3VA99880AB13
€25.06
Tax included
€25.06
Tax included
Tax included
-20€
EXTRA
Add the coupon code in the payment page
Limited-time promotion
Items Available: 30
: 4
Pay in installments with Klarna
Features:
- Siemens Series
- Rated insulation voltage Ui 690 V
- Rated impulse withstand voltage 4 kV
- Rated operational voltage Ue with AC 50 Hz 24 V
- Rated operational voltage Ue with DC 24 V
- Thermal current 0.3A
- Pollution degree 3
- Overvoltage category III
- Stripping length 15 mm
- Height 56 mm
- Width 7 mm
- Width / note 1 connector position (7 mm)
- Depth 30 mm
- Net weight 30 gr
There are no reviews
Data sheet
- Type: Auxiliary Contacts
